Overview
The Four Cylinder Four Stroke Diesel Engine Test Rig represents a standard truck or marine diesel engine configuration for advanced teaching and applied research. Coupled to a high-capacity eddy current or hydraulic dynamometer, the rig allows measurement of full-load and part-load performance over the complete speed range. Students generate power, torque, BMEP, and BSFC maps, perform heat balance analysis, and measure smoke opacity and exhaust emissions. The multi-cylinder platform is suitable for studying turbocharging, EGR, and after-treatment system effects, providing a comprehensive platform for diesel engine research.
Specifications
| Engine type | 4-cylinder |
| 4-stroke | |
| diesel | |
| turbocharged (optional) | |
| Total displacement | 1500 to 3000 cc |
| Dynamometer | eddy current or hydraulic |
| high capacity | |
| Speed range | 600 to 4000 RPM |
| Fuel | diesel |
| measured by mass flow meter | |
| Exhaust | CO |
| HC | |
| NOx | |
| smoke analyser | |
| Turbocharger | fitted (optional) |
| Power supply | 415V AC |
| 3-phase | |
| 50 Hz | |
